SC UPC Single Mode To Multimode Fiber Patch Cord Pigtail 0.9mm OM1 OM2

Brand Name:	KEXINT
Model Number:	KXT-P-0.9
MOQ:	100
Price:	$+0.275+1pcs
Packaging Details:	1 pcs One bag , 250pcs One small box , 1500pcs one carton
Payment Terms:	D/A, L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

IS0 9001

Name:

Fiber Optical Pigtail Patch Cord

Length Of Cable:

1m 1.5m

Type Of Fiber:

657A1 657A2 G657B3 G652D

Mode Of Fiber:

Insertion Loss:

0.2db

Reture Loss:

55 DB

Color:

Yellow

Optical Cable Outer Diameter:

0.9MM

Supply Ability:

2500 pcs 1day

Highlight:

Single Mode To Multimode Fiber Patch Cord Pigtail

SC UPC Fiber Patch Cord Pigtail

0.9mm Fiber Patch Cord Pigtail Yellow

Product Description

SC/UPC Single Mode To Multimode Fiber Patch Cord Pigtail 0.9mm OM1 OM2

Pigtail refers to an optical fiber or optical cable with an optical fiber active connector installed at one end and an optical fiber or optical cable at the other end. Dividing an optical jumper into two becomes two optical pigtails. Optical pigtails are usually used for the termination of the optical path (such as the terminal point pair with the actual test result box, the splice tray in the wiring equipment, etc.). Or the extraction of optical devices (such as optical splitters, lasers, detectors, etc.).

Key Features:
1) Low Insertion loss
2) Low PDL
3) Compact Design
4) Good channel-to-channel uniformity
5) Wide Operating Wavelength: 1260-1650nm
6) Wide Operating Temperature: -40°C - 85°C
7) High Reliability and Stability

Specification :

Mode	SM		MM
Polish	UPC	APC	PC
Insertion Loss	Typical ≤0.2dB Maximum ≤0.3dB		≤0.25dB
Return Loss	≥50dB	≥65dB	≥35dB
Interchangeability	≤0.2dB
Repeatability	≤0.1dB
Durability	≤0.2dB (1000 times mating)
Tensile Strengh	> 10kg
Temperature	≤0.2dB (-40+85 sustain 100 hours)
Humidity	≤0.2dB (+25+65 93 R.H.100 hours

Application :
1) FTTX Systems

2) PON Networks

3) CATV Links

4) Optical Signal Distribution

5) Local Areal Networks (LAN)

6) Fiber Communication Systems

Ordering Options:

1) Connector type: FC, SC, LC, ST
2) Ferrule End-face: PC, UPC, APC
3) Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
4) Cable Quantity: Simplex, Duplex
5) Cable Diameter: φ3.0mm,φ2.0mm, φ0.9mm
6) Cable Length: 1, 2, 3 meter or customized
7) Cable Type: PVC, LSZH.

SC UPC Single Mode To Multimode Fiber Patch Cord Pigtail 0.9mm OM1 OM2 0

SC UPC Single Mode To Multimode Fiber Patch Cord Pigtail 0.9mm OM1 OM2 1

SC UPC Single Mode To Multimode Fiber Patch Cord Pigtail 0.9mm OM1 OM2 4
