FTTH 32 Cores Fiber Optical Distribution Box KEXINT KXT-16I With PLC ABS PC White

Brand Name:	KEXINT
Model Number:	KXY-16I
MOQ:	10 Pieces
Price:	10 - 499 pieces $20.8 ; 500 - 999 pieces $18.8 ; >= 1000 pieces $16.8
Packaging Details:	Inner Carton+Outer Carton
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong，China

Certification:

CE/ROHS/ISO9001

Color:

White

Weight:

0.5 KG

PLC Installation:

Support

Connector Type:

SC FC LC ST

Dimensions:

380*320*115mm

Material:

ABS+PC

Single-Mode Fiber::

APC/UPC

Max Capacity:

Inlet/Outlet Port:

4/2

Package:

Carton Box

Working Temperature:

-40℃~85℃

Warranty Time:

2 Years

Supply Ability:

100000 Piece/Pieces per Week

Highlight:

32 Cores Fiber Optical Distribution Box

Fiber Optical Distribution Box With PLC

IP68 Waterproof Fiber Optic Distribution Box

Product Description

Description:

The equipment is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing, splitting, distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTX network building.

Features:

Total enclosed structure.

Material: PC+ABS, wet-proof, water-proof, dust-proof, anti-aging, protection level up to IP68.

Clamping for feeder cable and drop cable, fiber splicing, fixation, storage, distribution all in one.

Cable, pigtails, and patch cords are running through their own paths without disturbing each other, micro type PLC splitter

installation, easy maintenance.

Distribution panel can be flipped up, feeder cable can be placed by expression port, easy for maintenance and installation.

Box can be installed by the way of wall-mounted or poled-mounted, suitable for both indoor and outdoor use.

Specification
Parameter

			Material

			PC+ABS

			Dimension (Pic 1) A*B*C(mm)

			380*320*115mm

			Max Capacity

			32 ports SC

			Input cable diameter(mm)

			Max 18mm

			Color

			White

			Working temperature

			-40℃~+85℃

			Relative humidity

			≤85%(+30℃)

			Atmospheric pressure

			70KPa~106Kpa

			item

			value

			Model Number

			KXT-16I

			Brand Name

			KEXINT

			Use

			FTTH

			Warranty Time

			3 years

			Network

			None

			Dimensions

			380*320*115mm

			Material

			ABS+PC

			Color

			White

			Inlet/Outlet port

			4/2

			Connector Type

			SC FC LC ST

			PLC installation

			Support

			Certification

			CE/ROHS/ISO9001

			Package

			Carton Box

			Single-Mode Fiber

			APC/UPC

			Max Capacity

			32
